Product Overview
Power Transformer Bushing
Power Transformer Bushing is selected for power and energy projects where electrical performance, mechanical compatibility, installation conditions and long-term reliability must be considered together. The final configuration should be based on the actual system data, equipment interface, site environment and project specification rather than on the product name alone.
WishPower supplies Power Transformer Bushing for utility, industrial, renewable-energy and infrastructure applications. Customers can provide drawings, technical data sheets, single-line diagrams, cable or equipment dimensions, and reference models so that the required configuration can be reviewed before production. This helps reduce installation mismatch and supports more accurate technical approval.
Product Features
- Electrical insulation design selected according to the stated voltage range and bushing construction.
- FRP composite or porcelain external insulation can be coordinated with the actual product type.
- Draw-lead, guidebar, transformer or equipment interfaces are confirmed from project drawings.
- Flange dimensions, terminal geometry and insertion length can be reviewed for OEM or replacement applications.
- Creepage distance and external profile are selected according to pollution severity, altitude and outdoor exposure.
- Project-specific marking, documentation and export packing can be prepared.
Technical Specifications
| Technical Item | Project / Selection Requirement |
|---|---|
| Rated voltage / voltage range | According to the stated bushing product and equipment system |
| Rated current | Confirmed according to transformer or equipment current requirement |
| Insulation level | According to project insulation coordination |
| External insulation | FRP composite or porcelain according to product type |
| Flange / mounting interface | Customized to equipment drawing |
| Creepage distance | Selected according to pollution and environment |
| Terminal / conductor interface | According to draw-lead, guidebar or equipment design |
| Installation orientation | Confirmed from transformer or equipment layout |
Applications
- Power transformers
- High-voltage substations
- Circuit breakers or cable interfaces where applicable
- OEM electrical equipment
- Replacement and refurbishment projects
- Utility and industrial high-voltage systems
Interface Data for Power Transformer Bushing
Bushings are interface-critical components. For a new design, provide flange dimensions, terminal geometry, conductor size, insertion length, installation angle and required insulation level. For replacement work, the original bushing drawing is the preferred reference because even small dimensional differences can affect fit, sealing and electrical clearances.
Selection Considerations
Voltage class alone does not define the complete bushing. Rated current, insulation level, creepage distance, pollution severity, altitude and the medium on each side of the mounting flange should also be confirmed before production.
WishPower Project Support
WishPower supports project-based supply of Power Transformer Bushing from technical inquiry through drawing confirmation, production coordination and export delivery. To prepare an accurate quotation, provide the available specification, project quantity, installation conditions, interface drawings and destination.
Where an exact rating, dimension or standard is not available in the legacy title, the original project data should be confirmed before exact numerical claims are published. This keeps the restored product page technically accurate while preserving the original search intent.
Technical Specifications
Product Structure
Main Applications
Testing Capability
Packaging & Transportation
To keep products safe during transportation and storage, we use the following packaging methods:
- Individual Packaging: Each product is wrapped with protective film, packed in a high-strength carton, and cushioned with buffer materials.
- Pallet Packaging: Multiple products are fixed on wooden pallets and wrapped with stretch film, suitable for container shipping.
- Export Packaging: Fumigated wooden cases, moisture-proof treatment, and detailed packing lists are provided according to sea freight requirements.
Customization Service
Wishpower can provide the following customization options according to customer requirements:
- Structural Dimensions: Adjust overall height, creepage distance, shed quantity, and shed diameter.
- End Fittings: Customize ball-socket, tongue-clevis, eye, or other interface types according to connection requirements.
- Color: Standard gray, with red, yellow, blue, and other colors available subject to MOQ.
- Special Environments: Formulations for extreme cold (-60 C), strong UV exposure, heavy pollution, and other harsh conditions.
- Voltage Classes: Full-range customization from 10kV to 1000kV.
- Marking: Customer logos or model numbers can be molded or printed on the product.
For specific customization requirements, please contact our sales engineers. We will provide a technical solution within 24 hours.
